THG 7000 Full-Height PCI Bracket – DB9 Cutout – Nickel-Plated SPCC Steel

Part Number: THG-7000

Note: This site does not process orders online. Please use the 'Contact Us' to request a quote. Items in your cart are not processed.

The THG-7000 is a full-height PCI bracket designed with a DB9 (D-Sub 9-pin) connector cutout, used for RS-232 serial ports, automation hardware, and industrial communication systems. DB9 remains one of the most widely used serial interfaces in manufacturing, CNC equipment, PLC control systems, legacy communication hardware, and POS systems.

Manufactured from SPCC cold-rolled steel and finished with nickel plating, this bracket offers reliable rigidity, corrosion resistance, and a quality appearance for OEM and industrial builds. The bracket includes the standard PCI mounting tab and a 5° alignment bend, ensuring proper seating inside full-height computer chassis.

Specifications:

• Material: SPCC CRS Steel (Cold Rolled Steel)

• Thickness: 0.80 mm (0.031 in)

• Finish: Nickel Plating

• Bracket Type: Full-Height PCI

• Connector Cutout: DB9 (D-Sub 9-Pin)

• Height: 114.94 mm (4.525 in)

• Width: 18.42 mm (0.725 in)

• Bend Angle: 5°

• Tolerance: ±0.05 mm

Applications:
Ideal for:

• RS-232 DB9 communication ports

• Serial automation equipment

• POS hardware

• Custom OEM I/O breakout panels

• Industrial computers / expansion modules

Customization:
Custom labeling, plating finishes, and alternate connector layouts available upon request.

The THG-7000 is a nickel-plated SPCC steel PCI bracket with a precision DB9 connector cutout. The bracket includes a 5° seating bend and standard PCI screw tab to ensure secure mechanical alignment and reliability in industrial, automation, and OEM serial communication hardware.
