THG 7056 Full-Height PCI Bracket – DB37 Cutout – Nickel-Plated SPCC Steel

Part Number: THG-7056

Note: This site does not process orders online. Please use the 'Contact Us' to request a quote. Items in your cart are not processed.

The THG-7056 is a full-height PCI computer bracket designed with a precision DB37 (D-Sub 37-pin) connector cutout. DB37 connectors are commonly used for industrial automation systems, multi-signal serial communication, breakout boxes, and CNC equipment.

Manufactured from SPCC cold-rolled steel, this bracket provides rigidity and long-term durability. The nickel-plated finish resists corrosion while offering a clean, professional appearance inside any PC or industrial enclosure. The design features the standard PCI mounting tab and a 5° alignment bend to maintain correct positioning when installed.

Specifications:

• Material: SPCC CRS Steel (Cold Rolled Steel)

• Thickness: 0.80 mm (0.031 in)

• Finish: Nickel Plating

• Bracket Type: Full-Height PCI

• Connector Cutout: DB37 (D-Sub 37-pin)

• Height: 114.94 mm (4.525 in)

• Width: 18.42 mm (0.725 in)

• Bend Angle: 5°

• Tolerance: ±0.05 mm

Applications:
Ideal for DB37 connectors used in CNC systems, industrial control modules, automation interfaces, and serial breakout communication assemblies.

Customization:
Custom plating (zinc, nickel, black oxide), labeling, and alternate connector patterns available on request.

The THG-7056 is a nickel-plated SPCC steel PCI bracket designed for DB37 connectors. It features precision cutout geometry, standard PCI screw tab, and a 5° mounting bend for secure chassis alignment. Built for demanding OEM and industrial automation applications where durability and connector accuracy are critical.
